O-Rail

Design with No Limits

Modular linear guides with rollers.
Versatile for the highest flexibility of configurations.

The original shape of the FXRG guide features 3 raceways arranged at 90°, over which the R series rollers can run on any one of the 3 raceways.

Select your O-Rail
versatile

Versatile for
multiple configurations

The original shape of the FXRG guide
features 3 raceways arranged at 90°.
Linear Rails - O-Rail
Modular linear guides with rollers
Self-aligning system

Self-aligning system

• axial ±1 mm
• rotational ±5°
simple mounting

Simple mounting

Using single or multiple parallel guides
allows users to achieve several combinations.
Linear Rails - O-Rail
versatile

High load capacity

Thanks to double row bearings
mounted on the sliders.



Linear Rails - O-Rail
Long life

Resistant to wear

Find out the technical details and
select your O-Rail.

O-Rail

Self-aligning linear roller guide for smooth and silent movement
43
CAD FileCatalogView technical details
