Linear Rails

Most Wanted

Compact Rail & Compact Rail Plus

Self-aligning linear guides with bearings and a C-profile made of cold-drawn carbon steel, induction hardened and ground raceways.

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
TLC KLC ULC				ROLLERS		15000	-20°C/+120°C
TG/TMG				ROLLERS		10800	-20°C/+120°C

Linear bearings with bended C-profile. Available in zinc-plated steel, stainless steel or hardened with Rollon NOX treatment

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
TEX TES UEX UES				ROLLERS		1740	-20°C/+100°C TEX-UEX -20°C/+120°C TES-UES
TEN/TEP UEN				ROLLERS		3240	-30°C/+150°C

Linear ball rails with single slider or multiple sliders

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
SN				BALLS		122000	-20°C/+170°C
SNK				BALLS		10858	-20°C/+70°C

Curvilinear rails with radial ball bearing rollers

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
CKR CVR CKRH CVRH CKRX CVRX				ROLLERS		2475	-20°C/+80°C

Modular linear guides with rollers.

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
FXRG				ROLLERS		4000	-20°C/+120°C

Prismatic rails with bearings and induction hardened v-shaped raceways.

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
P				ROLLERS		15000	-10°C/+80°C

Self-supporting linear rail in extruded aluminum with steel rollers covered in plastic compound.

Product	Slider	Load capacity [n] F_x	Operating temperature
SR35	ROLLERS	400	-30°C/+80°C
SRC48	ROLLERS	540	-30°C/+80°C
SR	ROLLERS	14482	-30°C/+80°C

Re-circulating ball profiled linear rails with high load capacity

Product	Section	Hardened	Self alignment	Slider	Anticorrosion	Load capacity [n] F_x	Operating temperature
MR				BALLS		249000	-10°C/+60°C
MMR				BALLS		8385	-20°C/+80°C
